Description
Diagnostic device for motor vehicles and motorbikes. A diagnostic system with an intuitive and easy-to-understand user interface in 10 languages. The simple symbol-based menu structure helps the user to complete his tasks quickly and reliably. The extensive functions and special features provide the user with a unique diagnostic system. It is impossible to imagine a modern car / two-wheeler workshop without this diagnostic device.
Supported control units:
- Engine electronics / engine control unit CDI
- Central electronics / chassis electronics BCM
- Instrument cluster / speedometer
- Tire pressure monitoring RDKS
- ABS - anti-lock braking system
- Anti-theft alarm system / Alarm system
- Radio / Multimedia
- Radio control unit
- Electric Hydraulic Tilt Stand
- Battery Management System BMS
- Integrated Supply Control Module ICSM
- Electric power steering EPS
- Electronic power throttle EPT
- Exhaust flap control FCE
- Keyless GO System
- Headlights LED
- Automatic gearbox / transmission control
- Traction control
- Airbag
Diagnostic functions / diagnostic options:
- Service reset / Service reset / DESMO / Oil
- Read and delete fault memory completely
- Key programming
- Set injection system
- Unlocking the immobilizer
- Throttle valve setting / adaptation
- Date and time setting e.g. after battery replacement
- Reset adaptation values
- Specific actual/target values / live data
- Read current KM and software
- Read out chassis number
- Valve clearance service reset
- Bleed ABS pressure modulator / Bleed test from ABS hydraulic system
- Brake wear indicator Initialize
- Windshield calibration
- ESA/SAF shock absorber calibration
- Stepper calibration
- Calibration of height sensor, windshield, idle speed adjuster, foil sensor etc...
- Calibration of sensors e.g. exhaust flap, interference tube flap, reversing aid setting, drive value sensor, gearbox, idling actuator, lambda sensors etc...
- Actuator diagnostics e.g. fan, injection nozzle, valves
- Tire pressure sensor RDC teach-in - programming - initialization
- No limitation or restriction to models
Technical features:
- 3.5-inch IPS color display with high resolution
- Robust housing with ergonomic handles
- Graphical user interface via clear icons
- Long metal dome keys on membrane keypad
- Rubber-protected housing
- Battery-free operation, power supplied by the machine
- Update via USB-C standard cable
- Software updates automatically via Windows software
- Dimensions L/W/H 17x11x4cm Weight 300g
Supports the following KTM models (with OBD EURO5 / ISO19689 diagnostic cable):
- 150 EXC TPI
- 250 EXC TPI
- 250 XC-W TPI
- 300 EXC TPI
- 300 XC-W TPI
- 1290 Super Adventure R / S / 3.0 Euro 5
- 1290 Super Duke R / GT / 3.0 Euro 5
- 125 / 250 / 390 / 790 / 890 Duke
- 690 Enduro R / SMC R
- 390 / 890 Adventure L / R
